Impact's Mini Industrial Computers are ideally suited for low power applications, that still require high power graphics, at entry level price points. All configurations are fully FCC/B & CE certified, with 5-7 year lifecycles. Additional Info: Other Sizes, AI-Grade Computers, and Accessories
Contact us to configure the right solution.
Smallest ECX Fanless Atom System (E300)
165 mm x 109 mm x 40 (or 48) mm (W x H x D)
Optional CPU support:
- Intel® Atom® x5-E3940 Processor
- Intel® Atom® x7-E3950 Processor
Standard Features:
- Fanless design without vents
- Intel® HD Graphics
- 2x HDMIs, 2x GbE LANs
- 4x USBs 3.0, 2x RS232/422/485
- 1x Micro-SD Cage for storage
Customizable Options:
- WiFi/Bluetooth
- Extended temp. avail -20 °C ~ 70 °C
- DDR3L SO-DIMM RAM
- mSATA / mPCIe for SSD
- 2242 or 2280 SSD via M.2 Key B
- Infineon SLB 9665 TPM 2.0
- VESA Mount
ECX Fanless Intel U-Series System (E210)
220 mm x 153.3 mm x 38 mm (W x H x D)
Optional CPU support:
- Intel® Kaby Lake Celeron® 3965U Processor
- Intel® Skylake Core™ i5-6300U Processor
- Intel® Kaby Lake Core™ i3-, -5, -7 -7XXXU Processors
Standard Features:
- Fanless design without vents
- Intel® HD Graphics
- 1x HDMI 2.0, 1x DP
- 2x GbE LANs, 4x USBs 3.0
- 2x RS232/422/485, 1x DIO
Customizable options:
- WiFi/Bluetooth
- Extended temp. avail -20 °C ~ 70 °C
- DDR4 SO-DIMM RAM
- 1x 2.5” SATA 3.0 HDD / SSD
- 1x mPCIe, 1x M.2 for 2242 SSD
- Infineon SLB 9665 TPM 2.0 for Core i5 & i7
- VESA Mount
Mini-ITX Fanless Intel Celeron System (M100)
220 mm x 180 mm x 68 mm (W x H x D)
Optional CPU Support:
- Intel® Celeron® J1900 Processor
Standard Features:
- Fanless design
- Intel® HD Graphics
- 1x HDMI, 1x VGA
- 2x GbE LANs for Ethernet
- 1x USBs 3.0, 5x USBs 2.0
- 8x RS232's, 2x RS232/422/485
- 1x Parallel Port
Customizable Options:
- DDR3L 1333 SO-DIMM RAM
- 2.5” SATA 2.0 HDD/SSD or 1x mSATA
- Infineon SLB 9635 TPM 1.2
- Two wall mount brackets
Kontron Intel-CPU and AMD-CPU based solutions fit into small spaces without sacrificing top of the line processing power. Let Impact customize the right solution for applications requiring the cutting edge Intel and AMD features in a compact form factor.
Mini-STX Fanless AMD Ryzen System
147 x 165 mm x 36 mm (W x H x D)
Optional CPU support:
- AMD Ryzen R1102G (Dual-Core, 1.2GHz base) Processor
- AMD Ryzen R1305G (Dual-Core 1.5GHz base) Processor
Standard Features:
- Fanless design
- AMD Radeon™ Vega GPU
- TPM security chip
- 1x HDMI & 1x DP for -R1
- 1x HDMI & 2x DP for -R2
- Headset Jack & Stereo Mic
- 5x USB A & 1x USB-C
- 2x LANs
Customizable Options:
- COM port (like RS232/422/485)
- WiFi/Bluetooth
- up to 32GB RAM
- NVME or SATA SSD
- Wall Mount or VESA
Mini-STX Fanless Intel System
188.8 x 153.4 x 78 mm (W x H x D)
Optional CPU support:
- Intel 8th and 9th Gen Core i Processors T Series
- Intel® Pentium processors
- Intel® Celeron processors
Standard Features:
- Fanless design
- Intel® UHD Graphics 630
- TPM security chip
- 1x Display Port
- 1x HDMI port
- 7x USBs
- 1x USB-C
- 1x LAN
Customizable options:
- DDR4 RAM up to 32GB
- M.2 NVME SSD drive up to 2TB
- 2nd LAN
- WiFi/Bluetooth
D3654-B data sheet
Mini-STX Intel System With Fan
146.5 x 164 x 34 mm (W x H x D)
Optional CPU Support:
- Intel 6th, 7th, 8th or 9th Gen Core i Processors
- Celeron or Pentium processors
- up to 65W only
Standard Features:
- Intel® UHD Graphics 630
- PWM fan max 3W @ 5V
- TPM security chip
- 1x Display Port
- 1x HDMI port
- 6x USBs
- 1x LAN
Customizable Options:
- DDR4 RAM up to 32GB
- M.2 NVME SSD drive up to 2TB
- WiFi/Bluetooth
D3654-B data sheet
Kontron Intel-CPU and AMD-CPU based solutions fit into small spaces without sacrificing top of the line processing power. Let Impact customize the right solution for applications requiring the cutting edge Intel and AMD features in a compact form factor.
Mini-STX Fanless Gemini Lake System
146.5 x 164 x 34 mm
Optional CPU support:
- Intel® "Gemini Lake" Celeron J4105 (QuadCore 2.5GHz, 10W TDP)
- Intel® "Gemini Lake" Celeron J4005 (DualCore 2.7GHz, 10W TDP)
- Intel® "Gemini Lake" Pentium J5005 (QuadCore 2.8GHz, 10W TDP)
Standard Features:
- Fanless design
- Intel® UHD Graphics 600
- Front Audio
- 2x DP1.2
- 6x Front & Rear USB (4x USB 2.0, 2x USB 3.1)
- 1x COM Port (plus 1x internal)
- 2x SATA 6Gb/s
- Wall mount included
Customizable Options:
- DDR4 2400Mhz RAM up to 16GB’s
- M.2 SSD drive up to 1TB
- WiFi
Mini-ITX Gemini Lake System
250 x 191 x 52 mm
Optional CPU support:
- Intel® "Gemini Lake" Celeron J4005 (DualCore 2.7GHz, 10W TDP)
- Intel® "Gemini Lake" Celeron J4105 (QuadCore 2.5GHz, 10W TDP)
- Intel® "Gemini Lake" Pentium J5005 (QuadCore 2.8GHz, 10W TDP)
Standard Features:
- 1x Intel® GbE LAN, 1x RTL GbE LAN
- 2x DP1.2
- 2x COM Ports (2x ext., 2x int.)
- 4x USB 2.0, 2x USB 3.0, 2x USB 3.1, 1x USB 2.0 Stick
- Integrated Intel® UHD Graphics 600 12EUs @700 MHz or 750MHz; or 605 18EUs @800MHz
Customizable options:
- DDR4 2400Mhz RAM up to 32GB’s
- WLAN antenna integrated into front bezel
- M.2, mPCIe or SATA SSD or spinning drive up to 2TB’s
D3543-S data sheet
Mini-ITX AMD
System
250 x 191 x 52 mm
Optional CPU Support:
- AMD GX-222GC (2.22 GHz/10-15W) DualCore, w. AMD Radeon™ R5E Graphics
- AMD GX-412HC (1.20 GHz/5-7W) QuadCore w. AMD Radeon™ R3E Graphics
- AMD GX-424CC (2.4 GHz/25W) QuadCore w. Radeon™ R5E 655/800MHz Graphics
Standard Features:
- 1x DVI, 1x DP v1.2
- 8 x USB 2.0, 2x USB 3.0
- 1x Parallel
- Dual GbE LAN
- High Definition Audio Output
Customizable Options:
- DDR3 1600 SDRAM up to 16GB
- WLAN support
- mSATA, or SATA SSD or spinning drive up to 2TB’s
D3313-S data sheet
Kontron Intel-CPU and AMD-CPU based solutions fit into small spaces without sacrificing top of the line processing power. Let Impact customize the right solution for applications requiring the cutting edge Intel and AMD features in a compact form factor.
Thin-Mini-ITX Intel System
307 x 190 x 36.8 mm
Optional CPU Support:
- Intel 6th, 7th, 8th, 9th Gen Core i Processors
- Celeron or Pentium processors
Standard Features:
- 1x GbE LAN
- 1x DP1.2, 1x HDMI
- VESA mounting
- Kensington lock
Customizable Options:
- DDR4 2400Mhz RAM up to 32GB
- M.2 SSD up to 1TB
- WLAN/BT options
D3674-B data sheet
D3674-B chassis specs
Mini-ITX Intel
System
250 x 191 x 52 mm
Optional CPU support:
- Intel 6th, 7th, 8th, 9th Gen Core i Processors
- Celeron or Pentium processors
Standard Features:
- 2x Intel® GbE LAN
- 2x DP1.2, DVI-D
- 2x COM ports
- High Definition Audio
Customizable Options:
- DDR4 2133Mhz RAM up to 32GB
- PCI Express x16 (Gen. 3) expansion slot
- M.2 SSD or Spinning HD up to 2TB
- WLAN/BT options
